View product VTRA 750Venturi VTRA · Ref. VTRA250
High-vacuum conveying vacuum pump with ring-adjustable flow: draws in and conveys powders, granules and small parts using compressed air alone.
Product added to your cart
Video
The VTRA 250 Venturi pneumatic conveyor reaches a vacuum of −84 kPa and draws up to 280 NL/min (at −17 kPa). Its Ø 6.5 mm inner bore and Ø 19 mm outer diameter make it suitable for dense materials and long distances.
Compact and adjustable, it suits low flows of powders and granules, for example when unloading a vibratory bowl.
Compressed air, connected to port G2, is accelerated through an annular nozzle: it creates strong vacuum at the suction port (G1) and propels the material to the outlet (G3). The rotating ring changes the air gap and lets you adjust suction flow by hand, without tools.
The body is made of light, corrosion-resistant anodised aluminium. All ports are female threaded (parallel G thread) for direct mounting on your pipework.
Dimensions, performance and weight of the VTRA range: the row framed in red is the VTRA 250.
To recommend the ideal model, please prepare the following information:
How it works
A Venturi conveyor turns compressed air into powerful suction, with no motor and no moving parts. Simply connect it to your air supply and to a conveying hose.
Air enters through the side port and fills an annular chamber around the central bore.
Air is accelerated through nozzles pointing towards the outlet, creating strong vacuum at the inlet.
Powders, granules, chips or small parts are drawn in through the inlet hose.
The air stream carries the material to the discharge point, with no risk of clogging.
FAQ
The VTRA 250 has an internal bore of Ø 6.5 mm. To convey without clogging, the largest particle dimension should not exceed about one third of this diameter, i.e. about 2 mm. For larger pieces, choose a model with a larger bore.
At 5.5 bar, the VTRA 250 uses from 112 NL/min (at −17 kPa) to 342 NL/min (at −84 kPa), depending on the ring setting. The compressed air must be dry and filtered.
With the rotating ring, by hand and without tools: you favour either flow, up to 280 NL/min at −17 kPa, or vacuum, up to −84 kPa; at −84 kPa it still draws 125 NL/min. Supply pressure: 5.5 bar (7 bar maximum).
All connections are female BSPP (parallel G) threads: suction G1/4, compressed air G1/8 and discharge G1/4. The internal bore is Ø 6.5 mm.
