Venturi VTRF
Straight-through bore from Ø 6.5 to 38 mm and very high suction flow, up to 5,610 NL/min.
- Max. vacuum
- −35 kPa
- Max. flow
- 5,610 NL/min
- Models
- 6
from €165.00 excl. VAT
VTRF rangeVenturi conveying vacuum pumps
Venturi pneumatic conveyors for powders, granules and small parts
Convey your materials using compressed air alone: no motor, no moving parts, no maintenance. VTRF and VTRA ranges in anodised aluminium, delivered within 2 weeks.
- Straight-through, no clogging
- No moving parts
- Tracked worldwide shipping
- Delivery within 2 weeks
Our ranges
Two ranges of Venturi conveyors
VTRF for high straight-through flow, VTRA for high, adjustable vacuum.
Venturi VTRA
High vacuum down to −84 kPa and flow adjustable by rotating ring.
- Max. vacuum
- −84 kPa
- Max. flow
- 3,390 NL/min
- Models
- 4
from €230.00 excl. VAT
VTRA rangeCatalogue
All our pneumatic conveyors
10 models in anodised aluminium, from Ø 6.5 mm to Ø 38 mm.
Venturi VTRF
VTRF 2-3 Venturi pneumatic conveyor
- −26 kPa
- 295 NL/min
- Ø 6.5 mm
from €165.00 excl. VAT
View product VTRF 2-3
Venturi VTRF
VTRF 3-3 Venturi pneumatic conveyor
- −16 kPa
- 425 NL/min
- Ø 9.5 mm
from €195.00 excl. VAT
View product VTRF 3-3
Venturi VTRF
VTRF 5-6 Venturi pneumatic conveyor
- −35 kPa
- 870 NL/min
- Ø 12.5 mm
from €230.00 excl. VAT
View product VTRF 5-6
Venturi VTRF
VTRF 7-6 Venturi pneumatic conveyor
- −28 kPa
- 1,825 NL/min
- Ø 19 mm
from €270.00 excl. VAT
View product VTRF 7-6
Venturi VTRF
VTRF 15-3 Venturi pneumatic conveyor
- −4.4 kPa
- 4,400 NL/min
- Ø 25 mm
from €350.00 excl. VAT
View product VTRF 15-3
Venturi VTRF
VTRF 15-6 Venturi pneumatic conveyor
- −9 kPa
- 5,610 NL/min
- Ø 38 mm
from €375.00 excl. VAT
View product VTRF 15-6
Venturi VTRA
VTRA 250 Venturi pneumatic conveyor
- −84 kPa
- 280 NL/min
- Ø 6.5 mm
from €230.00 excl. VAT
View product VTRA 250
Venturi VTRA
VTRA 375 Venturi pneumatic conveyor
- −84 kPa
- 846 NL/min
- Ø 9.5 mm
from €250.00 excl. VAT
View product VTRA 375
Venturi VTRA
VTRA 500 Venturi pneumatic conveyor
- −70 kPa
- 1,695 NL/min
- Ø 13 mm
from €290.00 excl. VAT
View product VTRA 500
Venturi VTRA
VTRA 750 Venturi pneumatic conveyor
- −70 kPa
- 3,390 NL/min
- Ø 19 mm
from €375.00 excl. VAT
View product VTRA 750How it works
How does a Venturi pneumatic conveyor work?
A Venturi conveyor turns compressed air into powerful suction, with no motor and no moving parts. Simply connect it to your air supply and to a conveying hose.
- 1Compressed air injection
Air enters through the side port and fills an annular chamber around the central bore.
- 2Venturi effect
Air is accelerated through nozzles pointing towards the outlet, creating strong vacuum at the inlet.
- 3Material suction
Powders, granules, chips or small parts are drawn in through the inlet hose.
- 4Conveying and discharge
The air stream carries the material to the discharge point, with no risk of clogging.
Comparison
Which Venturi conveyor should you choose?
Compare vacuum, flow and bore diameter of all our models at a glance.
| Model | Max. vacuum−kPa | Suction flowNL/min | Inner bore (ØA)mm | Outer diameter (ØB)mm | Price fromexcl. VAT | View product |
|---|---|---|---|---|---|---|
| VTRF 2-3 | 26 | 295 | 6.5 | 18.5 | €165.00 | View VTRF 2-3 |
| VTRF 3-3 | 16 | 425 | 9.5 | 18.5 | €195.00 | View VTRF 3-3 |
| VTRF 5-6 | 35 | 870 | 12.5 | 24 | €230.00 | View VTRF 5-6 |
| VTRF 7-6 | 28 | 1,825 | 19 | 31 | €270.00 | View VTRF 7-6 |
| VTRF 15-3 | 4.4 | 4,400 | 25 | 38 | €350.00 | View VTRF 15-3 |
| VTRF 15-6 | 9 | 5,610 | 38 | 49.6 | €375.00 | View VTRF 15-6 |
| VTRA 250 | 84 | 280 | 6.5 | 19 | €230.00 | View VTRA 250 |
| VTRA 375 | 84 | 846 | 9.5 | 25 | €250.00 | View VTRA 375 |
| VTRA 500 | 70 | 1,695 | 13 | 32 | €290.00 | View VTRA 500 |
| VTRA 750 | 70 | 3,390 | 19 | 38 | €375.00 | View VTRA 750 |
Applications
A conveyor for every material
Our Venturi conveyors continuously transfer a wide range of materials across every industry.
-
Food industry
Cereals, grain, coffee, food pellets, sugar, seeds.
-
Plastics
Plastic pellets and regrind, injection hopper loading.
-
Pharma & chemicals
Powders, granules, tablets, capsules.
-
Machining
Removal of machining chips, grinding and drilling dust.
-
Paper, textile, packaging
Edge trim removal, paper, cardboard, textile, labels.
-
Automation
Feeding vibratory bowls and hoppers, small parts transfer.
Video
See the Venturi conveyor in action
Why Venturi?
The benefits of our pneumatic conveyors
A simple, sturdy and economical technology, tailored to your application.
-
No moving parts
No motor, no mechanical wear: outstanding reliability, even in continuous operation.
-
Straight-through, clog-free
The inner bore is completely unobstructed: material cannot block the conveyor.
-
Virtually maintenance-free
No special servicing: a simple compressed air connection is all it takes.
-
Adjustable flow
Flow is set by air pressure (VTRF) or by the adjusting ring (VTRA).
-
Anodised aluminium
A light, sturdy, corrosion-resistant body suited to most materials.
-
Expert advice
Our team helps you choose the right model for your material, distance and flow rate.
Easy ordering
From your requirement to delivery
- 1
Order or quote
Order online or describe your project: we recommend the right model.
- 2
Secure payment
Card, Apple Pay, Google Pay, PayPal (via Stripe) or bank transfer.
- 3
Manufacturing
Every conveyor is made to order: 1 to 2 weeks maximum.
- 4
Tracked shipping
Shipped to France, Europe and worldwide, with a tracking number.
FAQ
Frequently asked questions
What is a Venturi pneumatic conveyor?
It is a conveying vacuum pump that uses compressed air and the Venturi effect to draw in and convey materials (powders, granules, chips, small parts) through a hose, with no motor and no moving parts.
What is the difference between the VTRF and VTRA ranges?
VTRF conveyors deliver very high flow with a straight-through bore up to Ø 38 mm (up to 5,610 NL/min). VTRA conveyors reach a higher vacuum (up to −84 kPa) and feature a manual flow-adjusting ring.
What material are the conveyors made of?
The body is made of anodised aluminium: light, sturdy and corrosion-resistant, it suits the vast majority of industrial uses. For highly abrasive or corrosive materials, please contact us to discuss your application.
What are the delivery times?
All our conveyors are made to order: allow 1 to 2 weeks maximum between receipt of payment and dispatch, then 1 to 3 days within France and 3 to 7 days within Europe.
What air pressure is required?
VTRF conveyors run between 4 and 6 bar (7 bar max.), VTRA conveyors at 5.5 bar. Air must be dry and filtered for optimum performance.
How do I choose the right model?
The choice depends on the material (size, density, abrasiveness), the required flow, the conveying distance and height. Describe your project using our quote form and we will reply quickly with a recommendation.
Are prices shown excluding or including VAT?
Prices are shown excluding VAT and exclusive of shipping: a flat fee per order based on the delivery country (€35 excl. VAT for France), shown before payment. French VAT (20%) applies to deliveries in France; EU businesses with a valid VAT number benefit from the reverse-charge mechanism, and deliveries outside the EU are VAT-exempt.
Pneumatic conveying using the Venturi effect
A Venturi pneumatic conveyor — also called a conveying vacuum pump, air amplifier conveyor, ejector or eductor — is the simplest way to transfer bulk materials from one point to another. Powered by your plant’s compressed air, it generates vacuum that draws the material in and propels it through a flexible or rigid hose.
Unlike mechanical conveyors (screws, belts, turbine vacuum units), it has no moving parts: no wear, no lubrication, no risk of jamming. Its compact size makes it easy to fit onto an existing machine, hopper or machining station.
Our VTRF and VTRA ranges cover bores from Ø 6.5 to 38 mm, flows from 280 to 5,610 NL/min and vacuum levels down to −84 kPa, in anodised aluminium.
